| Brand Name: | DONGXIN |
| Model Number: | PH001 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 20 Sets/Month |
Stable Performance Automatic Weighing Machine is an industrial high-precision weighing and checkweighing solution designed for continuous factory production and packaging lines.
The machine combines high-precision load cells, digital weighing control, touchscreen operation, automatic overweight/underweight alarm and production-line connectivity, helping manufacturers improve weighing consistency while reducing manual inspection requirements.
With a configurable weighing range of 10–5000 g and accuracy of approximately ±0.1 g to ±1.0 g depending on product weight and operating speed, the system can be adapted to different industrial weighing requirements.
Industrial-grade load cells and digital signal processing provide stable measurement during continuous operation.
High accuracy / stable weighing / consistent measurement / automatic inspection
The weighing accuracy can reach: ±0.1 g to ±1.0 g
Actual accuracy depends on product weight, operating speed and production conditions.
The machine can be integrated into continuous conveyor-based production and packaging lines.
Maximum conveyor speed: Up to 60 m/min
Processing capability: Up to 120 pcs/min
This allows automatic weight verification without relying on repeated manual weighing.
The machine can be equipped with a 7-inch or 10-inch color touchscreen for convenient operation.
The HMI system supports:
Pre-programmed parameters help operators switch between different production requirements more efficiently.
The machine automatically compares the measured product weight with preset target values.
It can identify:
The system provides an overweight and underweight alarm to support production-line quality control.
Out-of-specification products can be automatically separated from the production flow.
Available rejector configurations include:
The appropriate rejection method can be selected according to product dimensions, weight and conveyor layout.
The weighing system supports data communication for modern factory management.
Connectivity options can include:
This allows weighing data to be exported or integrated with compatible factory management systems.
| Component | Function |
|---|---|
| High-Precision Load Cell | Measures product weight |
| Digital Weighing Controller | Processes weighing signals |
| Touchscreen HMI | Provides parameter setting and operation |
| Conveyor System | Transfers products through the weighing section |
| Weighing Platform | Performs dynamic weight measurement |
| Alarm System | Detects overweight and underweight conditions |
| Automatic Rejector | Removes non-conforming products |
| Electrical Control System | Controls automatic machine operation |
| Data Interface | Supports production data transmission |
| Safety System | Provides overload protection and emergency stop |
| Specification | Details |
|---|---|
| Product Name | Stable Performance Automatic Weighing Machine |
| Model Number | PH001 |
| Machine Type | Industrial Automatic Weighing Machine |
| Weighing Range | 10–5000 g, Customizable |
| Weighing Accuracy | ±0.1 g to ±1.0 g |
| Maximum Conveyor Speed | 60 m/min |
| Maximum Processing Speed | Up to 120 pcs/min |
| Display | LCD/LED Digital Display |
| Touchscreen Option | 7-inch / 10-inch Color Touchscreen |
| Interface | RS232 / USB |
| Extended Connectivity | USB / RS485 / Ethernet |
| Input Voltage | AC 220V 50Hz / AC 380V 50Hz |
| Machine Weight | 140 kg |
| Air Consumption | 3.0 L/min |
| Hopper Capacity | 25–40 kg, Single Bag Loading |
| Alarm System | Overweight & Underweight Alarm |
| Safety Features | Overload Protection / Emergency Stop |
| Frame Material | SUS304 Stainless Steel |
| Protection Grade | IP65 Standard / IP66 Optional |
| Rejector Options | Air-Blast / Pusher / Drop-Down |
| Brand | DONGXIN |
| Place of Origin | China |
| MOQ | 1 Set |
| Supply Ability | 50 Sets Per Month |
| Packaging | Stretch Film |
Dongxin provides customized automatic weighing solutions according to different materials, products and factory production-line requirements.
Standard weighing range: 10–5000 g
Customized weighing ranges can be discussed according to:
The machine can be configured according to the balance required between weighing accuracy and production speed.
Target parameters can be matched according to:
Different automatic rejection systems are available:
The appropriate structure can be selected according to the product being processed.
Available options include:
This allows international factory operators to manage different production programs more conveniently.
Standard options include:
Electrical specifications can be adjusted according to the destination country's factory power requirements.
Available connectivity can include:
The system can be configured for weighing data collection and compatible factory management requirements.
Suitable for automatic weight verification of:
The machine helps identify packages outside the preset weight range.
Suitable for:
Different weighing configurations can be selected according to the material and packaging format.
Applications include:
Weight checking can also help identify missing or incorrect quantities in packaged products.
The machine can be integrated into:
Automatic weighing provides an additional quality-control stage before final packing or shipment.
Suitable for:
Automatic weight measurement can support high-volume parcel processing operations.
Before machine configuration, production requirements are confirmed according to:
Main components are assembled, including:
The weighing and control system is configured according to machine requirements.
Main procedures include:
The weighing system is calibrated and adjusted according to the required measuring range.
Main checks include:
The machine undergoes operational testing before shipment.
Testing focuses on:
Main inspection items include:
The machine is tested before shipment to confirm stable operation of the main weighing and control functions.
Standard packaging: Stretch Film
Additional export protection can be arranged according to transportation requirements.
Available protection can include:
Available transportation solutions:
The machine can be shipped individually or together with other factory production equipment.
The standard listed weighing range is: 10–5000 g
Customized weighing ranges can be configured according to specific production requirements.
The listed accuracy range is approximately: ±0.1 g to ±1.0 g
Actual accuracy depends on product weight, production speed and operating conditions.
The system supports a maximum conveyor speed of approximately: 60 m/min
Depending on the product and production conditions, processing speed can reach: Up to 120 pcs/min
Yes.
The machine includes an overweight and underweight alarm system and can be configured with automatic rejection mechanisms such as:
This allows non-conforming products to be separated automatically.
Yes.
Dongxin can customize the machine according to your weighing range, required accuracy, production speed, rejector type, touchscreen size, voltage and data-interface requirements, allowing the equipment to be matched with different factory production lines.
